HAWE RZ Hydraulic Dual-Stage Radial Piston Pump
HAWE RZ Hydraulic Dual-Stage Radial Piston Pump
HAWE RZ hydraulic dual-stage radial piston pump combines a radial piston high-pressure pump with a gear-type low-pressure pump. It is used where rapid traverse and high-pressure working movement are required from a compact dual-stage hydraulic pump assembly.
- High-pressure operating pressure:-Up to 700 bar
- Low-pressure operating pressure:- Up to 200 bar
- Dual-stage pump design
- High-pressure delivery flow:- Up to 91.2 l/min at 1450 rpm
- Nominal speed:- 1450 rpm
- Combines radial piston and gear pump technology
- Multiple pressure connections possible
Share Product:
HAWE RZ hydraulic dual-stage radial piston pump is a compact hydraulic pump assembly that combines a radial piston high-pressure stage with a directly mounted gear-type low-pressure stage. HAWE designs the RZ as a classic dual-stage pump based on type R radial piston pump elements and a closed pump housing. This combined arrangement is useful when a hydraulic machine needs a higher flow rate for fast movement and a separate high-pressure flow for the working operation. Instead of using two fully separate pump units, the RZ integrates both delivery stages in one coordinated pump package.
The low-pressure gear pump is typically used for rapid traverse, filling movement or approach travel, while the high-pressure radial piston pump supplies the force required during the working stroke. HAWE offers the low-pressure flow is usually routed through a pressure-actuated idle circulation valve, allowing the system to switch over at a preset pressure. This makes the pump suitable for circuits where speed is needed at low load and pressure is needed once resistance increases. The closed housing allows installation outside an oil tank or inside a hydraulic power pack container, depending on the hydraulic system design.
HAWE RZ hydraulic dual-stage radial piston pump offers fine delivery flow gradation and multiple pressure connection possibilities. HAWE lists high-pressure radial piston pump performance up to 700 bar and low-pressure gear pump performance up to 200 bar, depending on the selected size and configuration. Typical applications include presses, fixtures, laboratory and testing equipment, lubrication systems and agricultural machinery where rapid movement and high-pressure operation are both required.
